4.3 inch 480x272 TFT LCD with touch screen



Product Description



Item:

4.3 inch TFT LCD display with touch screen

Model No:

SHX043B4001-T

Display Mode:

Normally White,Transmissive

Resolution:

480 x3 RGB x272

Crystal:

a-Si TFT active matrix

Color Filter Array:

R.G.B. Vertical Stripe

Outline Dimensions:(mm)

105.5(W) x 67.2(H) x 4.1(D)

Active Area(mm):

95.04(H) x 53.856(V)

Interface:

RGB 24Bit

View Direction:

12 O'clock

Touch Panel:

4 wire resistive

Working temperature:

-20~70°C

Storage Temperature:

-30~+80°C


We have other sizes of TFT LCDs from 1.44 inch to 5.0 inch for your selction. Contact us Now!
