Character LCD Module
Lummax offers a wide range of standard character LCD modules. The display formats are from 8x2 to 40x4. Our character LCD modules can be used in the applications like attendance machine, Printer, automotive, home AV products, white goods...etc
| Add to inquiry |
Display Format |
Picture | Model No. | Outline Dimension (mm) |
Viewing Area (mm) |
Dot Size (mm) |
Character Size (mm) |
Driving Method (Duty) |
Interface | LCD Color | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| STN Grey |
STN Yellow |
STN Blue |
|||||||||||
8x1 |
 |
84.0x44.0 | 62.0x17.8 | 1.28x1.32 | 6.72x11.12 | 1/8 | Parallel 6800 | Y | Y | Y |  |
||
8x2 |
 |
40.0x35.65 | 30.0x14.0 | 0.50x0.50 | 2.78x4.49 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
8x2 |
 |
40.0x30.0 | 30.0x14.0 | 0.50x0.50 | 2.78x4.49 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
16x1 |
 |
80.0x36.0 | 65.5x14.5 | 0.54x0.60 | 2.90x5.15 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
16x1 |
 |
122.0x33.0 | 99.0x24.0 | 0.92x1.10 | 4.84x8.06 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
16x2 |
 |
122.0x44.0 | 99.0x24.0 | 0.92x1.10 | 4.84x9.66 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
16x2 |
 |
80.0x36.0 | 64.3x16.0 | 0.56x0.61 | 2.96x5.16 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
16x2 |
 |
84.0x44.0 | 64.3x16.0 | 0.56x0.61 | 2.96x5.16 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
16x2 |
 |
85.0x30.0 | 64.3x16.0 | 0.56x0.61 | 2.96x5.16 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
20x2 |
 |
180.0x40.0 | 149.0x23.0 | 1.10x1.10 | 6.10x9.85 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
20x4 |
 |
98.0x60.0 | 77.0x25.2 | 0.56x0.56 | 2.96x4.78 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
24x2 |
 |
118.0x36.0 | 94.5x17.8 | 0.60x0.65 | 3.20x5.55 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
24x2 |
 |
109.0x29.0 | 96.3x19.6 | 0.60x0.65 | 3.20x5.55 | 1/33 | Parallel 6800 | Y | Y | Y | |
||
40x2 |
 |
182.0x33.5 | 154.4x16.5 | 0.60x0.65 | 3.20x5.55 | 1/16 | Parallel 6800 | Y | Y | Y | |
||
40x4 |
 |
190.0x54.0 | 149.0x30.0 | 2.78x4.89 | 1/16 | Parallel 6800 | Y | Y | Y | |
|||
Total 15 Records
